Smog
The AirBin - Smog series represents ZYLM Energy's premium solution for combating particulate air pollution in high-impact industrial and environmental settings. These Anti Smog Guns are powerful, high-volume dust suppression machines engineered to create a safer, healthier, and compliant work environment across construction, mining, waste management, and heavy industry. By transforming high-pressure water into a targeted, micro-fine mist, AirBin - Smog effectively knocks down airborne dust and harmful particulate matter (PM), drastically improving air quality and site visibility.
Technology
The core of the AirBin - Smog system lies in its advanced micro-mist aggregation technology. High-pressure water is forced through precision-engineered stainless steel nozzles, atomizing the water into fine droplets, typically ranging from 10 to 100 microns in size. This critical size range allows the water droplets to effectively collide with and encapsulate similar-sized airborne dust particles. A powerful, high-output fan then projects this dense mist over distances up to 100 meters, ensuring rapid and efficient dust capture and sedimentation, leading to a permanent reduction in airborne pollutants.
Sensors
The system can be integrated with various sensors for smart and automatic operation:
• Anemometers & Wind Sensors: To monitor wind speed and direction.
• Air Quality Monitors (AQMs): Measure PM2.5 and PM10 levels.
• Pressure Sensors: Maintain optimal pump pressure.
Controls
The AirBin - Smog series is designed for maximum operator control and automation:
• Remote Operation: Full control via a wired or wireless remote for start/stop, pump activation, fan speed, and oscillation angle adjustment.
• Automated Oscillation: Programmable horizontal oscillation (swivel) and vertical tilt (elevation) to cover vast areas efficiently without constant manual input.
• Emergency Stop: Clearly marked safety mechanism for immediate shutdown.
• Adjustable Flow Rate: Ability to modulate the water pump output to fine-tune mist density and water consumption based on the severity of the dust event.
Utility
• Construction & Demolition: Controlling dust from heavy machinery, excavation, and crushing activities.
• Mining & Quarrying: Suppressing fugitive dust generated during drilling, blasting, material handling, and transport.
• Waste Management: Mitigating dust and odor from landfills, recycling plants, and bulk material sorting areas.
• Industrial Sites: Dust control in cement plants, thermal power stations, steel mills, and storage yards.
• Bulk Ports & Terminals: Managing dust from loading, unloading, and storage of materials like coal, grain, and minerals.
MODELS
Model specifications and technical details for SMOG - 30
- Throw Range: Up to 30 meters
- Oscillation Range: 0° – 320°
- Throw Angle: Adjustable from −5° to +45°
- Control Options: Automatic / Manual
- Mounting Type: Skid-mounted
- Construction Material: Mild Steel
- Installation Height: 9 – 10 feet
Model specifications and technical details for SMOG - 50
- Throw Range: Up to 50 meters
- Oscillation Range: 0° – 320°
- Throw Angle: Adjustable from −5° to +45°
- Control Options: Automatic / Manual
- Mounting Type: Skid-mounted
- Construction Material: Mild Steel
- Installation Height: 9 – 10 feet
Model specifications and technical details for SMOG - 70
- Throw Range: Up to 70 meters
- Oscillation Range: 0° – 320°
- Throw Angle: Adjustable from −5° to +45°
- Control Options: Automatic / Manual
- Mounting Type: Skid-mounted
- Construction Material: Mild Steel
- Installation Height: 9 – 10 feet
Model specifications and technical details for SMOG - 100
- Throw Range: Up to 100 meters
- Oscillation Range: 0° – 320°
- Throw Angle: Adjustable from −5° to +45°
- Control Options: Automatic / Manual
- Mounting Type: Skid-mounted
- Construction Material: Mild Steel
- Installation Height: 9 – 10 feet
Key Technical Specifications
|
|
|
|---|---|
|
Max Throw
Distance:
|
Up to 30 meters
|
|
Water Flow Rate
(Max):
|
35.00 Liters Per Minute (LPM)
|
|
Total Power
Consumption:
|
10.00 KWH
|
|
Mounting:
|
Trolley or Fixed
|
Usage Scenarios
Small construction sites, internal demolition projects, localized material transfer points, and industrial plant interiors.
